Technical Specifications
See the product's technical specifications below.
Thread for fixing to the panel:M16 x 2
Outlet Connection (Coupling Thread):W 21,8 x 1/14 DIN 477-1 DIR EXT
Output Connection Standard:(2X) ABNT NBR 218-1
Passage Diameter:3 mm
Maximum Working Pressure:250 BAR
Working Temperature:-20°C to +65°C
Body Material:Forged Brass
Handwheel, Stem or Cable and Trigger Material:Forged Aluminum
Seal Material:Polyamide
