See the product's technical specifications below.
Gas Type: Argônio, Argonite, FM 200, Inergen, Nitrogênio, Novec 1230
Inlet Thread (Cylinder): 3/4" x 14 NGT
Outlet Connection (Coupling Thread): M24 x 1,5
Pneumatic Drive Connections: 2 Saídas
Passage Diameter: 12 mm
Siphon Tube Thread (Fishing): M16 x 1
Maximum Working Pressure: 126 BAR ou 250 BAR
Type of Safety Device: Ruptura
Burst Pressure: 200 BAR ou 405 BAR
Working Temperature: -30°C a +80°C
Body Material: Latão Forjado
Connection for Electric Drive (K85-45): SIM
